The SWC series door connectors offer reliable magnetic contact solutions for security systems. With durable ABS housing, long operational life, and sealed reed switches, they ensure accurate door status detection while preventing false alarms in both surface and recessed installations.
The DC101-Series surface mount magnetic contacts are designed for use in installations where a small, sealed unit is required. The reed switch is totally encapsulated in an exclusive polyurethane potting compound preventing moisture from entering the switch and causing false alarms.
SWC/DCNC101
Model
SWC/DCNC101
Operating gap
≥25mm (Undisturbed test)
Max. switching voltage
100V DC/AC
Max. switching current
0.5A
Operating load
10W
Working temperature
-20~80℃
Working life
>100,000 times
Connection type
2 Pin terminal
Material
ABS
Color
White / Brown
Packaging
10 sets/bag, 600 sets/ctn
G.W.
10KGS
Description
Magnetic contact is widely used for alarm system(panel) to detect state of door. It consist of a reed switch part and a magnet part . When door closed, reed switch is effected by magnet and turn ON; when door open, reed switch iseffected by magnet and turn OFF, trigger alarm.
SWC/ DCB036
Model
SWC/ DCB036
Operating gap
20-30mm
Contact Type
Closed Loop
Contact Rating
Breakdown Voltage 100V / Max. Switch Current 0.5A
Housing
White, Brown, Grey ABS
Description
The DCB036-Series recessed mount magnetic contacts are designed for use in installations where a small, sealed unit is required. The reed switch is totally encapsulated in an exclusive polyurethane potting compound preventing moisture from entering the switch and causing false alarms
