M3 Pro
M3 Pro is a metal casing, IP65 water-proof design compact access control device, suitable for outdoor applications. It supports 13.56MHZ MIFARE card and 125KHZ EM card dual frequency module. The touch backlit keypad, support TCP/IP and RS485 communication convenient for customers to use.
Description
Specifications
Specifications
| Product Name | M3 Pro |
| Identification Mode | Password, Card |
| RFID Options | 125KHz EM & 1356MHz MIFARE |
| Max. Users | 10,000 |
| Max. Cards | 10,000 |
| Max. Logs | 100,000 |
| Group, Time Zone | 16 groups, 32 time zones |
| Web Server | Yes |
| Voice Prompt | Buzzer |
| Multiple Language | – |
| Software | CrossChex Standard |
| CPU | Linux 1.0 GHz |
| Sensor | – |
| Scanning Area | – |
| Display | – |
| Keypad | Touch Active |
| Dimensions(W x H x D) | 124x47x22mm (4.8″x0.85″x0.87″) |
| Working Temperature | -30°C~60°C (-22°F~140°F) |
| Humidity | 20% to 90% |
| PoE | – |
| Power Input | DC12V |
| Protection Class | IP65, IK10 |
| TCP/IP | Yes |
| RS485 | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Relay | Yes |
| I/O | Door Contact/Exit Button |
| Tamper Alarm | Yes |
| Anti-pass Back | – |
| Wiegand | Output |
